MIL-A-81371(AS)
(10) Switch S3 "Off"
(11) Pin 10 at a "l".
(12) Switch S1 "Off".
(13) Pin 10 at a "O".
6.10.7.2.5
Count Seven or More Transfer
(1) Switch S4 "On".
(2) Reset
(3) Pin 10 at a "1".
(4) Switch S1 "On".
(5) Pin 10 at a "1".
(6) Switch S1 "Off".
(7) Pin 10 at a "l".
(8) Repeat steps (4), (5), (6), and (7), six times
(9) Switch S1 "On".
(10) Pin 10 at a "l".
(11). Switch S4 "Off".
(12) Pin 10 at a "1".
.
(13) Switch S1 "Off".
(14) Pin 10 at a "O".
6.10.7.3
Right Hand Stores Check (see figure 3)
6.10.7.3.1
Switch Transfer
(1) Switch S5 "On".
(2) Reset
18
